RoHS Ce FCC Certified Clip on Scope Night Vision for Hunting and Outdoor Observation
Basic Info
| Model NO. | Guide TA435 |
| Customized | Non-Customized |
| Weight | 350g |
| Resolution | 400X300 |
| Focus Length | 35mm F1.2 |
| Frame Rate | 50Hz(PAL), 60Hz(Nstc) |
| Product Name | IR Thermal Scope |
| Digital Zoom | 2X, 4X |
| Battery | Cr123ax2/Icr16340X2 |
| Operating Temperature | -30ºC-50ºC |
| Transport Package | IP67 |
| Specification | 150mm*52mm*57mm |
| Trademark | Guide |
| Origin | China |
| Production Capacity | 200 Units Per Month |
Product Description
Wholesale Guide TA435 Versatile Clip on Thermal Hunting Scope
Clip on scope/ Thermal Imaging Scope Front Attachment/ Day Night System
Description
Guide TA435 clip on thermal Hunting Scope is a truly versatile and convenient thermal imaging scope with increased options and functionality. You can use it as a dedicated thermal scope or clipped on in front of your regular day time scope for high quality night vision experience. No need re-zero, no need remove your daytime scope. Just "clip on" right in front of the daytime optics.
Application
Hunting
Outdoor observation and aiming
Wild Adventure
Law Enforcement
Security, search and rescue
Features and Benefits
• Versatile: You can use it as a dedicated thermal scope or clipped on in front of your regular day time scope for high quality night vision experience.
• Simple & Adaptable: Switchover among five scene modes by one button, truly realizing all-weather environment self-adaptation
• Convenient: You neither have to re-zero your scope, nor do you have to remove your regular daytime scope in order to install this one. Just "clips on" right in front of it.
• Compact and lightweight: less than 400g
• OLED color eyepiece display, capable of displaying images in various color modes
• Waterproof IP67
• Super sound-off and bright light Cut-off System, prevent exposure
• Optional Bluetooth remote controller for easy operation
• Quick mount and no-shot zero (recommended magnification of the day scope/sight : 2-4X)
Specification
Detector | |
Resolution | 400×[email protected]μm |
Spectral Range | 8μm~14μm |
NETD | ≤[email protected]ºC /F1.0 |
Focus lens | |
Focal Length | 35mm F1.2 |
Focusing | Manual focus |
FOV | 10.66°×8.0° |
Image Processing | |
Frame Rate | 50Hz(PAL)/60Hz(NSTC) |
Digital Zoom | 2×,4× |
Auto Tracking | Hotspot track |
Calibration | Automatic calibration/ Manual calibration (shutter) /Manual scene compensation |
Color Palettes | Black hot, white hot, red hot, green hot |
Contrast/Brightness | Adjustable |
Power Systems | |
Battery | CR123A×2/ICR16340×2 |
Charging | On External charger |
Working Time | Continuous Operating over 3 [email protected]ºC |
Interface | |
4-Pin LEMO Interface | Analog&video output |
Display system | |
OLED | Colorful 0.39 inch OLED screen 1024×768 |
Pupil Distance | 10mm |
Pupil Caliber | 20mm |
Video Format | PAL/NTSC |
Digital Zoom | 1 |
View Finder | Monocular display(×2) ±5 adjustable diopter |
Environment parameter | |
Operating Temperature | -30ºC-50ºC |
StorageTemperature | -45ºC-70ºC |
Humidity | Working and storage10% ~ 95%, Non condensing |
Impact | 500G/1ms |
IP level | IP67 |
Certificate | RoHS Certificate/CE Certificate/FCC Certificate |
Physical Characteristics | |
Weight | ≤400g |
Size | 150mm×52mm×57mm |
Package | |
Standard | Thermal infrared imager/User manual/Blinder/Warranty |
Optional | Adapter ring/External eyepiece/ |
CR123A×2(unrechargeable)battery/ICR16340×2(rechargeable) battery/Charger/Bluetooth remote controller/Lemo video cable/Picatinny rail | |
Cover ring adapterA:Compatible with 38/40/42/44/46mm; | |
Cover ring adapterB:Compatible with 48/50/52/54mm; | |
Cover ring adapterC:Compatible with 56/58/60/62/64mm; | |
Detection Range | |
Human:1.8m×0.5m | 1000m |
Vehicle:2.3m×2.3m | 2400m |
Recognition Range | |
Human:1.8m×0.5m | 500m |
Vehicle:2.3m×2.3m | 1000m |
